BDS 4 Inch Lift Kit for 2011-2016 Ford F250/F350 Super Duty 4WD Gas

Key Features

• Easy, 100% bolt-on installation
• Full-length, gas-specific Pro-Ride dual-rate coil springs deliver correct lift height and a smooth, predictable ride across varied terrain
• Heavy-duty radius arm drop brackets maintain correct caster and preserve stock driving characteristics
• Forged drop pitman arm and heavy-duty track bar drop bracket keep steering angles in phase through suspension travel and recenter the front axle
• Steel rear lift blocks with built-in bump stop provide a level front-to-rear stance
• Standard NX2 Nitro shocks with vehicle-specific valving for improved control
• Optional upgrade to FOX 2.0 Performance Series shocks for maximum on- and off-road performance
• U-bolt flip kit for added rear ground clearance

Shock Options

NX2 Nitro Series: Nitrogen-charged, twin-tube design with 10-stage velocity-sensitive valving, dual-welded ends for added strength, a 1-3/8-inch high-flow piston, self-lubricating seals, and a silver powder coat finish.

FOX 2.0 Performance Series: 2-inch impact extruded aluminum body with an internal floating piston (IFP) monotube design, CNC-machined 6061-T6 aluminum mounting ends, a 5/8-inch hard chrome-plated heat-treated alloy steel shaft, race-developed high-flow piston, application-specific valving, and a clear anodized finish.

Rear Lift Options

Block Kit: Cast iron construction for strength, tapered for correct pinion angle, with an offset steel pin and hole to restore axle position.

Leaf Springs: Eliminates the need for a lift block, reduces axle wrap for a more controlled and stable feel, uses a multi-leaf progressive design for a smooth ride, and maintains factory payload weight ratings.

Recommended Tires & Wheels

Trimming may be required.

• 35 x 12.5 with 17 x 9, 4.5 in. backspace
• 35 x 12.5 with 18 x 9, 4.5 in. backspace
• 35 x 12.5 with 20 x 9, 4.5 in. backspace

Fitment

Fits 2011-2016 Ford F-250 and F-350 Super Duty, 4WD, FLEX fuel:

• F-250 Super Duty (4WD): XL, XLT, Lariat, King Ranch (2011-2016); Platinum (2013-2016)
• F-350 Super Duty (4WD): All submodels (2011-2016)

Important Notes

• Removal of the factory block is required.
• A rear add-a-leaf is required on models equipped with the factory 3-7/8" block to achieve a level to tail-high stance. Single add-a-leaf kit #113218 is recommended for a more level stance; dual add-a-leaf kit #113209 is recommended for a tail-high stance. (Add-a-leafs do not apply to rear leaf spring equipped systems.)
• Front exhaust modification may be required to clear the front driveshaft (gas only).
• If equipped with a 2-piece driveshaft, a driveshaft alignment kit may be required.
• Although extremely rare, front and/or rear driveline vibration may occur.
• If equipped with a rear sway bar, #123009 is required.
• U-bolts will not work on dually models.
